Trumpf Trubend 5130

Ref.0268

Trubend 5130 (2021)

• Machine - C frame,
• Press beam,
• Spherical bearing of the press beam with press beam tilting,
• On-Demand Servo Drive with 4-cylinder technology,
• Distance measurement system (Y axis) with dynamic deflection compensation,
• Hydraulic oil filling (life-long fill),
• Backgauge - Gauge fingers (two pieces).

MACHINE OPTIONS:

• Extension of the open height/stroke + 230 mm,
• CNC-controlled wedge crowning,
• 5-axis backgauge (X, Delta X, R, Z1, and Z2 axis),
• TRUMPF hydraulic upper tool clamp,
• Keyboard and mouse,
• Additional screen,
• Shop floor programming,
• TecZone Bend Tool Setup Optimizer (TSO),
• ACB Wireless (Automatically Controlled Bending),
• ACB Laser (Automatically Controlled Bending),
• Tool Indicator, Part Indicator,
• Front work area illumination, Rear work area illumination,
• Support bracket x 2,
• BendGuard Automatic.
